Camera đo nhiệt độ Fluke Ti 10

Liên hệ

Add to wishlist
SKU: Ti 10 Danh mục: Thẻ: , , , , , Thương hiệu:

Mô tả

Máy chụp ảnh nhiệt Fluke Ti10

Thông số kỹ thuật:

9 Hz Thermal Imager w/ 20 mm lens
AC power supply/battery charger (including mains adapters)
SD memory card
SD card reader (USB) for downloading images into your computer
SmartView™ software with free software upgrades for life
Rugged hard carrying case
Soft transport bag
Hand strap
Users manual
Warranty registration card
Temperature
Temperature measurement range (not calibrated below -10°C)-20°C to +250°C (-4°F to + 482°F)
Temperature measurement accuracy±2°C or 2% (at 25°C nominal, whichever is greater)
Imaging Performance
Field of view23° x 17°
Spatial resolution (IFOV)2.5 mRad
Minimum focus distanceThermal lens: 15 cm (6 in)
Visible (visual) light lens: 46 cm (18 in)
FocusManual
Image frequency9 Hz refresh rate
Detector type160 x 120 focal plane array, uncooled microbolometer
Infrared lens type20 mm F = 0.8 lens
Thermal sensitivity (NETD)≤ 0.13°C at 30°C target temp. (130 mK)
Infrared spectral band7.5 μm to 14 μm
Visual camera640 x 480 resolution
Image Presentation
PalettesIronbow, blue-red, high contrast, grey
Level and spanSmooth auto-scaling and manual scaling of level and span
Minimum span (in manual mode)5°C (9°F)
Minimum span (in auto mode)10°C (18°F)
Fast Auto/Manual Range Toggle Fast Auto Rescale
IR-Fusion® informationFull infrared or picture-in-picture
Picture-In-Picture (PIP)100% IR displayed in center 320 x 240 pixels
Full screen (PIP off)100% IR displayed in center 640 x 480 LCD
PalettesIronbow, blue-red, high contrast, grey
Image Capture and Data Storage
Storage mediumSD memory card (2 GB memory card will store at least 1200 fully radiometric (.is2) IR and linked visual images each or 3000 basic (.bmp) IR images)
File formatsNon-radiometric (.bmp) or fully-radiometric (.is2)
No analysis software required for non-radiometric (.bmp) files
Export file formats w/SmartView™ softwareJPEG, BMP, GIF, PNG, TIFF, WMF, EXIF, and EMF
General Specifications
Operating temperature-10°C to +50°C (14°F to 122°F)
Storage temperature-20°C to +50°C (-4°F to 122°F) without batteries
Relative humidity10% to 95% non-condensing
Display9.1 cm (3.6 in) diagonal landscape color VGA (640 x 480) LCD with backlight (selectable bright or auto)
Controls and adjustmentsUser selectable temperature scale (°C/°F)
Language selection
Time/Date set
SoftwareSmartView® full analysis and reporting software included
BatteriesInternal rechargeable battery pack (included)
Battery lifeThree to four hours continuous use (assumes 50% brightness of LCD)
Battery charge timeTwo hours for full charge
AC operation/chargingAC adapter/charger (110 V AC to 220 V AC, 50 Hz to 60 Hz). Charges battery while imager is operating. Universal AC mains adapters included.
Power savingSleep mode activated after five minutes of inactivity, automatic power off after 20 minutes of inactivity
Safety standardsCE Directive: IEC/EN 61010-1 2nd Edition Pollution Degree 2
Electromagnetic compatibilityEMC directive: EN61326-1 C-Tick: IEC/EN 61326 US FCC: CFR 47, Part 15 Class A
Vibration2 G, IEC 68-2-29
Shock25 G, IEC 68-2-29 {2 m (6.5 ft) drop, 5 sides}
Dimensions (H x W x L)0.27 x 0.13 x 0.15 m (10.5 x 5 x 6 in)
Weight1.2 kg (2.65 lb)
IP ratingIP54
WarrantyTwo-years
Calibration cycleTwo-years (assumes normal operation and normal aging)
Supported languagesCzech, English, Finnish, French. German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish

Thông tin bổ sung

Cân nặng1.2 kg
Công nghệ

Mỹ

Xuất xứ

Mỹ

Bảo hành

12 Tháng
