Máy khoan từ Ruko RSM40e
Mô tả
Máy khoan từ Ruko RS40e/RSM40e.
Magnetic-stand drilling machine RS40e / RSM40e
Like Magnetic-stand drilling machine RS30e in additional it works clockwise and counter-clockwise and with electronic controlled speed
| Technical data: | |
| Magnetic clamping force RS40e: | 13.000 N |
| Magnetic clamping force RSM40e: | 20.800 N |
| Total Power consumption: | 1.840 Watt |
| Rotation speeds: | 1st gear: 60 – 140 r.p.m. |
| 2nd gear: 200 – 470 r.p.m | |
| Height: | 450,0 – 640,0 mm |
| Lift: | 190,0 mm |
| Length and width RS40e: | 190,0 x 90,0 mm |
| Length and width RSM40e: | 220,0 x 110,0 mm |
| Weight RS40e: | 24,0 kg |
| Weight RSM40e: | 30,0 kg |
| Adapter: | Morse taper MT 3 |
| Drill chuck: | 3,0 – 16,0 mm |
| Drilling range: | |
| Twist drills (DIN 338): | max. Ø 16,0 mm |
| Twist drills (DIN 345): | max. Ø 31,5 mm |
| Core drills: | up to Ø 100,0 mm |
| Cutting depth core drills: | 30,0 / 50,0 mm |
| Thread cutting: | up to M 30 |
| Auxiliary controller: | |
| Turn field: | +/- 20° |
| Moveable field: | +/- 7,5 mm |
| Input voltage: | 230 V |
| Conformity with: | VDE, CEE |
| Accessories: | |
| 1 Plastic tool case 1 Drill drift 1 Drill chuck 3,0 – 16,0 mm article no. 108 117 1 Spike cone MT 3 / B16 article no. 108 121 1 Cooling bottle including holding device article no. 108 101 1 Safety belt 1 Operating instructions 1 with arbor article no. 108 316 for core drills with Weldon shank |
|
| Description | Article no. |
| Magnetic-stand drilling machine RS40e | 108 004 RS |
| Magnetic-stand drilling machine RSM40e | 108 004 RSM |
Thông tin bổ sung
| Cân nặng | 30.0 kg |
|---|---|
| Công nghệ | Đức |
| Xuất xứ | Đức |
| Bảo hành | 12 Tháng |
